The Rhino is an industrial lighting system to suit warehouse and retail applications. The product comprises of a powder coated steel trunking body with a polycarbonate optical chamber. The luminaire has a maximum output of 13,900lm whilst achieving an efficacy of 190lm/W.
The luminaire can be used surface or suspended with a variety of beam angle options to achieve maximum utilisation.
More than 50,000 hours life span
Colour consistency with <3 SDCM
Assured build quality with die-cast based construction
5 Year Warranty
| Type | Options | Code |
|---|---|---|
| Lumen Output | 6,810lm 9,560lm 13,900lm | RHO/6810 RHO/9560 RHO/13900 |
| Colour Temperature | 3000K 4000K 6500K | /3K /4K /6K |
| Beam Angle | 30° 60° 90° 120° Diffused Asymmetric Double Asymmetric | /30 /60 /90 /120 /DF /AS /DAS |
| Type | Options | Code |
|---|---|---|
| Mounting | Suspended | -S |
| Dimming | DALI Dimming Switch dim/Touch dim Casambi dimming | -DA -SD -CA |
| Sensor | Sensor (Daylight & dectection) Sensor Dim (Daylight & dectection | -S1 -S2 |
| Emergency | 3 Hour Facility 3 Hour Self Test 3 Hour Central Test | -E1 -E2 -E3 |
Supplied with high performance Lumileds LED engine and premium driver to ensure an outstanding performance with longevity.
120° Beam Angle
| Lumen Output | Wattage | ll/cW |
|---|---|---|
| 6,810lm (4000K) | 35.4W | 192.4 ll/cW |
| 9,560lm (4000K) | 49.1W | 194.7 ll/cW |
| 13,900lm (4000K) | 70.8W | 196.3 ll/cW |
| CCT | 3000K 4000K 6500K |
| Beam Angle | 30° 60° 90° 120° Diffussed Asymmetric Double Asymmetric |
| Light Source | SMD |
| SDCM | 3 |
| Longevity (L70/B10) | 60,000 hours |
| Colour Rendering | RA>82 |
| UGR | <22 |
| IP Rating | IP20 |
| Construction | Steel Body Polycarbonate Lens |
| RAL Colour (Other colours available upon special request) | RAL9016 (Standard) RAL9017 |
| Mounting Method | Surface Suspended |
| Protective Class | I |
| Impact Resistance (IK) | IK08 |
| Warranty | 5 Years |
| Certification | UKCA, CE, ROHS |
| Rated Supply Voltage | 220 – 240 V |
| AC Voltage Range | 198 – 264 V |
| Mains Frequency | 50/60 Hz |
| Output LF current ripple @ 120Hz (Flicker) | <5% |
| Overvoltage Protection | 320 V |
| In-rush Current | 7.5 A |
| THD | <10% |
| Power Factor | 0.95 |
| Parasitic Load | 0.9W |
| Operating Temperature | -25 +60°C |
| Standard Lumen Output | EOF | Emergency Lumen Output |
|---|---|---|
| 6,810lm | 8% | 537lm |
| 9,560lm | 6% | 543lm |
| 13,900lm | 4% | 549lm |
| Emergency Duration | 3 Hours |
| Recharge Period | 24 Hours |
| Battery Type | LiFePO4 (Lithium Iron Phosphate) |
| Battery Pack | 3 x 3.2V 1.5Ah |
| Parasitic Load | 1.2W |
| Operating Tempertaure | 0 – 60°C |
| Power Efficiency | 95% |
| Certification | UKCA, CE, ROHS |
